Blue Sea Systems 4322 Water-Resistant Circuit Breaker Switch Panel, Gray, 6 Positions
4.8 (105 items)
Limited Time SaleUS$26.71 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 210271554 | Release Date | 2026/04/02 | List Price | US$17.81 | Model Number | 210271554 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Blue Sea Systems Water-Resistant Circuit Breaker Panel, 6 Positions, Gray. Nominal Voltage: 12V DC, Max Operating Amperage: 45A, Terminal Type: 1/4" Male Quick Connect, Hardware: Stainless Steel #6 x 5/8" mounting screws, Ring Terminal Size: M5 (#10)..Illuminated 15A circuit breakers provide switching, ON indication and overcurrent protection.Industry-standard sizes and mounting allow these panels to be easily retrofitted in an existing application.Polycarbonate/ABS panel surface is UV-stabilized, flame retardant, and will not corrode.Silicon breaker boots and gasket protects against water ingress. Panel front is IP66 when mounted with gasket in place - protected against powerful water jets (see inside back cover)..
- Blue Sea Systems Water-Resistant Circuit Breaker Panel, 6 Positions, Gray. Nominal Voltage: 12V DC, Max Operating Amperage: 45A, Terminal Type: 1/4" Male Quick Connect, Hardware: Stainless Steel 6 x 5/8" mounting screws, Ring Terminal Size: M5 (10).
- Illuminated 15A circuit breakers provide switching, ON indication and overcurrent protection
- Industry-standard sizes and mounting allow these panels to be easily retrofitted in an existing application
- Polycarbonate/ABS panel surface is UV-stabilized, flame retardant, and will not corrode
- Silicon breaker boots and gasket protects against water ingress. Panel front is IP66 when mounted with gasket in place - protected against powerful water jets (see inside back cover).
- Fit type: Universal Fit
| UPC | 632085043223 |
|---|---|
| Color | Gray |
| Model | 4322-BSS |
| Wattage | 1800 watts |
| Terminal | Quick Connect,screws |
| Brand Name | Blue Sea Systems |
| Unit Count | 1.0 Count |
| Item Weight | 0.01 Ounces |
| Switch Type | Rocker |
| Circuit Type | 6-way |
| Contact Type | Normally Open |
| Manufacturer | Blue Sea Systems |
| Material Type | Plastic |
| Mounting Type | Panel Mount |
| Connector Type | Quick Connect,screws |
| Control Method | App |
| Current Rating | 45 Amps |
| Item Type Name | Water-resistant Panel |
| Operation Mode | ON-OFF |
| Controller Type | Ring |
| Item Dimensions | 1.75 x 4.63 x 6.63 inches |
| Number of Items | 1 |
| Contact Material | Copper, Brass |
| Operating Voltage | 12 Volts (DC) |
| Specification Met | ISO 9001 |
| Included Components | Panel,15 square labels, stainless steel #6 5/8" mounting screws, Instructions |
| Number of Positions | 6 |
| Warranty Description | Lifetime |
| Connectivity Protocol | X-10 |
| International Protection Rating | IP66 |
